MULTI 4000

The Multi 4000 is the largest of the range can cover a huge 150 hectares per day.

Ross McKenzie talks about his Multi 4000 on his farm in Riverton at the bottom of the South Island, New Zealand.

Versatile and easy to use.

The largest in our range of Tow and Ferts the Multi 4000 is perfect for those larger farms requiring a versatile machine for a variety of applications.

The Tow and Fert Multi 4000 is designed to be towed by a tractor of a minimum of 120hp.

It uses the PTO at 1000rpm for mixing, agitation, and hydraulics to run the specifically designed 3” trash pump found on all other Tow and Fert models for spraying.

With the patented agitation technology in the tank, you can simply empty 1-tonne bags of fine particle fertiliser directly into the water without any pre-mixing or messy work. Combined with the optional crane, you can load 5 tonnes of fertiliser product into the Tow and Fert Multi 4000 in just 15 minutes.

With up to a 24 metre spread, the Multi 4000 can cover 1 hectare in just 3 minutes at 12 km/hr (8 mph). With a capacity of up to 40 hectares per load, this Tow and Fert makes light work of a large job.

tank volume 4000 litres (1060 gallons)
spray width Up to 24 metres (72 feet)
application rate Variable from 50 – 500 litres/hectare
attachment style Trailed
attachment vehicle 120hp tractor or greater
agitation powered by PTO @ 1000 RPM
area per load approx. 30-40 hectares (75 – 100 acres)
pump model Metalform Stainless 3” Centrifugal Trash Pump
pump performance 1200 litres per minute at 0 metres lift. Max lift = 4 metres
pump powered by Hydraulics – 33 litres/min
dry weight 3,000kg (without crane)
full weight up to 9,500kg (depending on mix SG)
size 5.90m (L) x 2.30m (W) x 2.50m (H)
Optional Extras Crane Kit. Dual Actuation. Horticultural Booms.
